Induction hob with integrated extractor fan, stand-alone 5IX 99300

5IX99300

A++ energy efficiency class
90cm width
Smart slider
Combi induction
Touch Control
Boost function
Residual heat display

Hob

Voltage: 220–240 V
Total connected load: 7.4 kW

4 induction cooking zones with booster:

4 cooking zones Ø 19.0 cm × 21.0 cm, 2.1 kW (3.7 kW)

Extractor fan

Voltage: 220–240 V
Total connected load: 7400 W
Energy efficiency class: A++
Average power consumption: 31.0 kWh/year
Fan efficiency class: A
Grease filter efficiency class: B
Noise level (in dB {A}) normal level max. extract air²
max. 67 dB(A)

Fan output max. normal level / intensive level*:

in extraction mode 570 m3/h / 665 m3/h
in circulation mode 540 m3/h / 630 m3/h

Hob

Frameless
Smart Slider
Touch control with slider function
4 induction cooking zones: 4 × Ø 19.0 × 21.0 cm (2.1 kW / 3.7 kW)
Flexible linking - two cooking zones can be combined into one cooking zone
Boost function for all induction cooking zones
Electronic control in 10 power levels
Automatic safety switch-off
Digital display of cooking levels in white
Pause und recall
Residual heat display
Safety switch-off
Pot detection
Child lock
Timer
Power management
Flush-mounted installation possible

Extractor fan

Electronic opening of the extractor fan
Glass ceramic, black
Suitable for installation in a kitchenette or kitchen island
Optional extraction or circulation mode (carbon filter required for circulation mode)
10-level fan power controllable via touch control (slider)
9 power levels + 1 intensive level
Intensive level with automatic reset for extraction mode
Metal grease filter and carbon filter saturation indication by LED control lamp
To clean the metal grease filter, the appliance automatically blocks after 30 hours of operation
Automatic overrun for circulation mode (20 minutes)
Water collection tank
Powerful and quiet blower
Metal grease filter, dishwasher-safe

Extractor fan

Metal grease filter, dishwasher-safe

Appliance dimensions: (H/W/D) 22.0 × 90.0 × 52.0 cm
Installation dimensions: (H/W/D) 22.0 × 90.0 × 52.0 cm

4251003109283

Air outlet/exhaust air duct to the left
It is not possible to plan in dishwashers, underframe coolers, base drawers etc. in the area of the exhaust air duct
Min. cabinet width 900 mm
Min. worktop depth 600 mm (correspondingly deeper when planning in niche panelling)
Base height min. 100 mm (depending on the duct system used)

Installation instructions

Instructions-for-installation-and-use-5IX99300.pdf10 MB

Technical data sheet

Energy label

Energy-label-5IX99300.pdf 63 KB

Technical drawing

Technical-drawing-5IX99300.png 163 KB

Special accessories

5Z9140X1
5Z9140X2
5Z9140X3
